Hue Light Effect
ActionStep Reference » Home Automation » Philips Hue » Light » Hue Light Effect
The ActionStep Hue Light Effect modifies the colors of the light from one color to another.
[-] Hide
- Open the Home Automation node in the Workspace Explorer.
- Open the Philips Hue node.
- In the Light node, select the Hue Light Effect ActionStep.
Parameters:
The ActionStep has the following input parameters:
| name |
Description
|
|---|---|
|
Hue Bridge
|
The control center for all smart-home devices.
Allowed Context Scope [Fixed] |
|
Light Name
|
The name of the light.
Allowed Context Scope [Fixed, Local, Global] Allowed Context Types [Variable, Parameter, Result, Enum] |
|
Effect
|
The color loop effect on the light.
Allowed Values: None or Color Loop Allowed Context Scope [Fixed]Allowed Context Types [Variable, Parameter, Enum] |
Results:
The ActionStep returns the following results:
|
name
|
description
|
|---|---|
|
Effect
|
The set color loop effect for the light.
Allowed Context Scopes [Fixed, Local, Global] Allowed Context Types [Variable, Parameter] |
Example 1 (Simultaneously run a color loop and an audio file):
This example runs the color loop effect and plays an audio file from a specified folder at the same time. The audio files were retrieved from local storage. After all audio files were played, the light is turned off and a text is output via Message Box.
